- Functional Description
- Specifications
- Applications
1、Provide 16V and 0-250mA for the DALI bus.
2、With overload and short circuit protection
型號 Type | JD-PS | ? | 執行標準/ Standards |
輸入電壓范圍/Input voltage range | 100～240 VAC | ||
輸入頻率/Input Frequency | 50/60Hz | ? | EN 55015 EN 61547 |
功率 /Power | 6W（Max） | ||
輸出電流 /Output Current | <250mA | ? | EN 61000-3-2 |
輸出電壓 /Output voltage | 16V±5% | ? | EN 61000-3-3 EN 61347-2-11 EN 62386-101 |
保護/Protection | 長時間短路保護, 自恢復 /protection for a long time short circuit, automatic recovery | ||
工作溫度 /Operating Temperature | 0～+50℃ | ? | ? |
保存溫度 /Storage Temperature | -10～+60℃ | ? | ? |
防護等級 / Degree of protection | IP20 | ? | ? |
?
-
